Oltre 330mm (13") Benchtop Thicknesser OT-TH-330

Oltre 330mm (13") Benchtop Thicknesser OT-TH-330

$999.00 AUD
$999.00 AUD
Sale Sold out

Features a six-row helical-style cutter head and 26 HSS insert cutters. Each indexable knife insert is precision sharpened on two edges and can be easily changed / rotated if damaged or worn - just loosen, rotate, and retighten! The alternating cutter pattern in the cutter head is super-efficient and produces a smooth cut surface. Features a threaded 4-post threaded housing for extra head stability when running, side handle for quick table height adjustments, repeat cut setting lever, large fold-up extension tables, flat top for stock returning, and side carry handles.

Features

  • Segmented Head Cutter Block (26 x HSS Cutters)
  • All Steel Construction
  • High-Speed Steel Insert Knives
  • Easy Blade Access
  • Substantial Infeed / Outfeed Table Extensions
Optional
  • 12-201 or sim. LED Gooseneck Worklight with Magnetic Base and Magnetic Clip
  • 25-410 or sim. Optional Planer Stand (Plywood/Wood Top Required for Mounting Machine to Stand)
  • 25-498 or sim. Replacement T25 Screws for 25-130H
  • 25-499C or sim. Replacement 2 Sided Carbide Inserts (10 Pack)

Specifications:

  • Motor power: 2.4HP / 1800W
  • Cutting capacity: 330mm (13") wide
  • Dust port size: 63.5mm/2.5"
  • Dust Collection Minimum CFM - 650CFM

Technical

Motor Power (Input) - 2.4HP / 1800W
Blade Type - Spiral Head Cutter Block
Blade - Cutter Head Block - Diameter - 50.8mm
Blade - Cutter Head Block Speed - 10000RPM
Cutting Capacity - Height - 3mm - 152mm
Cutting Capacity Width - 330mm
Blade Cutter Size - 14.2mm x 14.2mm x 2mm
Feed Speed - 7m/min
Power Source - 240V 50Hz Single Phase
Material (Stock) - Minimum Length - 177 mm
Material (Stock) Minimum Width - 19 mm

Packaging + Shipping

Shipping Length - 660 mm
Shipping Width - 400mm
Shipping Height - 540mm
Shipping Weight (Gross) - 35 kg
Packaging - Crated on skid
